TP-Link Omada ES205GP - 5-Port Gigabit Smart Switch with 4x PoE+
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
Compact wall-mountable 5-port Gigabit switch with 4 PoE+ ports, Omada easy management, 10 Gbps switching capacity — ideal for small offices and PoE devices.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 8000 entries. Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1p. IEEE 802.3at. IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE). Wall mountable
| Switch type | Managed |
| Feature | User guide |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.1Q. IEEE 802.1ab. IEEE 802.1p. IEEE 802.3at. IEEE 802.3x |
| Virtual LAN features | MTU VLAN. Port-based VLAN. Tagged VLAN |
| Transmission distance (max) | 0.25 km |
| Switching capacity | 10 Gbit/s |
| Forwarding rate | 7.4 Mpps |
| MAC address table | 8000 entries |
| Jumbo frames | 15 |
| Packet buffer memory | 4 MB |
| DHCP features | DHCP client |
| Product colour | Black |
| Power source | AC/DC |
| DC input voltage | 53.5 V |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 65 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Width | 100 mm |
| Depth | 98 mm |
| Height | 25 mm |
| Package type | Box |
| Compliance certificates | CE. Federal Communications Commission (FCC). RoHS |
