GIGABYTE Z890 AORUS ELITE WIFI7 LGA1851 ATX Intel Z890 DDR5 WiFi7
GIGABYTE Z890 AORUS ELITE WIFI7: LGA1851 ATX motherboard for Intel Core Ultra Series 2, Z890 chipset, 4x DDR5 up to 256GB, PCIe 5.0 GPU slot, 4x M.2 (1x PCIe5), Wi-Fi 7, 2.5GbE LAN, Thunderbolt 4. DIY-friendly with EZ-Latch.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The GIGABYTE Z890 AORUS ELITE WIFI7 is a high-performance ATX motherboard designed for Intel Core Ultra Series 2 processors using the LGA1851 socket and Intel Z890 chipset. It features a robust 16+1+2 phase digital VRM for stable power delivery, supporting dual-channel DDR5 memory up to 256GB across 4 DIMM slots with XMP profiles for overclocking up to 9200MT/s.
Storage and expansion are top-tier with 1x PCIe 5.0 x16 slot for GPUs, 4x M.2 slots (1x PCIe 5.0 x4, 3x PCIe 4.0 x4), 4x SATA 6Gb/s ports, and additional PCIe 4.0 x4 slots. Connectivity includes Wi-Fi 7 (MediaTek MT7925), Bluetooth, 2.5GbE LAN, Thunderbolt 4 Type-C, front USB-C 10Gb/s, multiple USB ports, and Sensor Panel Link for diagnostics. Premium features like VRM Thermal Armor, M.2 Thermal Guard, EZ-Latch for PCIe/M.2, and WIFI EZ-Plug enhance user experience.
- ✅ LGA1851 socket for Intel Core Ultra (Series 2)
- ✅ 4x DDR5 DIMMs, max 256GB, XMP support
- ✅ PCIe 5.0 x16 GPU slot + 4x M.2 (PCIe 5.0/4.0)
- ✅ Wi-Fi 7, 2.5GbE, Thunderbolt 4, USB-C 10Gbps
- ✅ EZ-Latch, Q-Flash, AI Perfdrive BIOS
| CPU Socket | LGA1851 (Intel Core Ultra Series 2) |
| Chipset | Intel Z890 |
| Form Factor | ATX (30.5 x 24.4 cm) |
| Memory Type | DDR5 Dual Channel |
| Memory Slots | 4 x DIMM, up to 256GB (64GB single) |
| Max Memory Speed | Up to 9200(O.C.) MT/s, XMP support |
| PCIe Slots | 1 x PCIe 5.0 x16 (CPU), 2 x PCIe 4.0 x4 (Chipset) |
| M.2 Slots | 4 (1 x PCIe 5.0 x4, 3 x PCIe 4.0 x4) |
| SATA Ports | 4 x SATA 6Gb/s |
| LAN | Realtek 2.5GbE |
| Wireless | Wi-Fi 7 MT7925 (802.11be), Bluetooth |
| USB Rear | 4 x USB 2.0, 2 x USB 3.2 Gen2, 3 x USB 3.2 Gen1, Thunderbolt 4 Type-C |
| USB Front | 1 x USB-C 10Gb/s, 1 x Sensor Panel Link |
| VRM | 16+1+2 phases Digital VRM |
| Audio | High-End Audio Capacitor |
| BIOS | AMI UEFI BIOS, Q-Flash, HyperTune AI |
| MPN | Z890 AORUS ELITE WIFI7 / Z890AORELWF7 |
