Gigabyte GeForce RTX 5070 EAGLE OC SFF - Black, 12GB GDDR7, OC 2587MHz, PCIe 5.0, GV-N5070EAGLE-OC-12GD
GeForce RTX 5070 EAGLE OC SFF with 12GB GDDR7, 6144 CUDA cores, 2587MHz boost clock, WINDFORCE 3X cooling with Hawk fans. Features Blackwell architecture, DLSS 4, NVIDIA SFF-ready design, RGB Fusion. 3xDP 2.1b, 1xHDMI 2.1b, 16-pin power, 750W PSU recommended.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
Experience next-generation gaming with the Gigabyte GeForce RTX 5070 EAGLE OC SFF 12G, powered by NVIDIA’s Blackwell architecture and DLSS 4 for AI-enhanced performance. This overclocked edition boosts to 2587MHz (reference 2512MHz) with 6144 CUDA cores, 12GB GDDR7 memory at 28Gbps on a 192-bit bus, delivering superior frame rates and ray-traced visuals.
The WINDFORCE 3X cooling system features Hawk fans, server-grade thermal gel, and alternate spinning for optimal airflow and low noise. NVIDIA SFF-ready design ensures compatibility with small form factor builds, while RGB lighting and reinforced structure add style and durability. Supports full ray tracing, NVIDIA Reflex 2, and up to 4 displays at 7680×4320 resolution.
- PCIe 5.0 x16 interface, 250W TGP, 1x 16-pin power connector
- Outputs: 3x DisplayPort 2.1b, 1x HDMI 2.1b
- Dimensions: 290 x 120 x 50 mm (2-slot ATX), black color with RGB
- Recommended PSU: 750W
| CUDA | Yes |
| CUDA cores | 6144 |
| Graphics processor family | NVIDIA |
| Graphics processor | GeForce RTX 5070 |
| Processor frequency | 2587 MHz (boost) |
| Maximum resolution | 7680 x 4320 pixels |
| Maximum displays per videocard | 4 |
| Discrete graphics card memory | 12 GB |
| Graphics card memory type | GDDR7 |
| Memory bus | 192 bit |
| Memory clock speed | 28000 MHz (28 Gbps) |
| Interface type | PCI Express x16 5.0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| DisplayPorts quantity | 3 |
| DisplayPort version | 2.1b |
| TV tuner integrated | No |
| DirectX version | 12 Ultimate (12 API) |
| OpenGL version | 4.6 |
| Dual Link DVI | No |
| Overclocked (OC) edition | Yes |
| Cooling type | Active |
| Cooling technology | GIGABYTE WINDFORCE 3X |
| Number of fans | 3 fan(s) |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Number of slots | 2 |
| Illumination | Yes (RGB) |
| Product colour | Black |
| Minimum system power supply | 750 W |
| Supplementary power connectors | 1x 16-pin |
| Length | 290 mm |
| Depth | 50 mm |
| Height | 120 mm |
| Package type | Box |
| Architecture | NVIDIA Blackwell |
| SFF-Ready | Yes |
