Chieftec Uni XT-01B-OP - Aluminum Mini Mid Tower micro-ATX Case, 340mm GPU
Aluminum mini mid-tower PC case for micro-ATX boards. GPU up to 340mm, CPU cooler to 140mm. 3x 3.5in bays, 2x 5.25in ext, 2x USB-A front. Supports 80-120mm fans front/rear. Compact: 180x352x408mm, 4.5kg.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Chieftec Uni XT-01B-OP is a compact aluminum mini mid-tower case designed for micro-ATX motherboards, ideal for space-conscious builds with solid cooling support.
It accommodates GPUs up to 340mm long and CPU coolers up to 140mm high, with 4 expansion slots, 3x 3.5″ internal bays (2 internal +1), 2x external 5.25″ bays, and 1x 2.5″ bay. Front panel features 2x USB 3.2 Gen1 Type-A ports and audio output. Fan support includes 1x 80/90/120mm front and 1x rear.
- Key Specs: Aluminum 0.6mm thick, 180mm W x 408mm D x 352mm H, 4.5kg
- Storage: Flexible 2.5″/3.5″ HDD support
- Cooling: Max 120mm fans, no radiator specified
- I/O: 2x USB-A, audio
| Material | Aluminium |
| Form factor | Mini Tower |
| Type | PC |
| Supported motherboard form factors | micro ATX |
| Number of 3.5 | 3 |
| Number of 5.25 | 2 |
| Number of 2.5 | 1 |
| Number of internal 3.5 | 2 |
| Number of external 5.25 | 2 |
| Number of expansion slots | 4 |
| Maximum CPU cooler height | 14 cm |
| Maximum graphics card length | 34 cm |
| Feature | Audio output |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Number of front fans supported (max) | 1 |
| Front fans diameters supported | 80,90,120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 80,90,120 mm |
| Supported HDD sizes | 2.5,3.5 |
| Width | 180 mm |
| Depth | 408 mm |
| Height | 352 mm |
| Weight | 4.5 kg |
| Material thickness | 0.6 mm |
| Harmonized System (HS) code | 84733080 |
| Included Fans | 0 |
