ASUS B650E MAX GAMING WIFI W - AM5 ATX Motherboard, DDR5, 4x DIMM, 256GB

ASUS B650E MAX GAMING WIFI W is a premium AM5 ATX motherboard engineered for AMD Ryzen 9000, 8000, and 7000 series processors. This motherboard combines robust power delivery with modern connectivity standards, featuring an 8+2+1 phase power design with discrete MOSFETs for stable performance. The board supports DDR5 memory with up to 256GB capacity across four DIMM slots, enabling high-speed computing for demanding applications and gaming workloads.

The motherboard excels in storage and connectivity with three M.2 slots (first slot supports PCIe 5.0 at 128Gbps for ultra-fast NVMe drives), four SATA III ports for traditional storage, and comprehensive I/O including WiFi 6E, 2.5Gb Ethernet, USB 10Gbps Type-C and Type-A ports, DisplayPort, and HDMI. Advanced features include ASUS OptiMem II technology for optimized memory bandwidth, comprehensive cooling solutions with VRM and M.2 heatsinks, and customizable RGB lighting via three Addressable RGB Gen 2 headers. The white PCB design and DIY-friendly features like BIOS FlashBack and pre-mounted I/O shield make this an excellent choice for PC builders seeking performance and aesthetics.

• Socket AM5 compatible with AMD Ryzen 9000/8000/7000 series processors
• DDR5 memory support with 4 DIMM slots, up to 256GB capacity
• PCIe 5.0 M.2 slot for next-generation NVMe SSDs at 128Gbps speeds
• WiFi 6E and 2.5Gb Ethernet for ultrafast wireless and wired connectivity
• 8+2+1 phase power design with discrete MOSFETs for stable power delivery
• Three M.2 slots with mixed PCIe generations (5.0, 4.0, 4.0)
• Four SATA III ports for additional storage drives
• USB 10Gbps Type-C and Type-A ports for high-speed peripheral connectivity
• Comprehensive cooling with VRM, M.2, and PCH heatsinks
• Three Addressable RGB Gen 2 headers for customizable lighting
