High-end 1000W ATX 3.0 PSU with 80+ Platinum efficiency, fully modular design, 1x PCIe 5.0 12VHPWR (600W), 140mm FDB fan, Japanese capacitors & full protections. Ideal for demanding gaming rigs with RTX 40/50 GPUs.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The XPH-1000W ATX 3.0 Platinum Power Supply from SAMA delivers reliable 1000W power for high-performance PCs. Compliant with Intel ATX 3.0 standards, it features a single PCIe 5.0 12VHPWR connector rated at 600W, perfect for modern GPUs like NVIDIA RTX 40/50 series. With 80 PLUS Platinum certification, it achieves up to 92% efficiency at 50% load, reducing heat and energy waste.
Fully modular ribbon cables simplify cable management, while the 140mm ECO Intelligent FDB fan ensures quiet, temperature-controlled cooling. Built with 100% Japanese 105°C capacitors and comprehensive protections (OVP, OCP, OPP, SCP, UVP, OTP, surge, inrush, no-load), it guarantees stability during power spikes up to 200%. Active PFC and universal 100-240VAC input support global use.
- Wattage: 1000W continuous
- Rails: +12V 80A (999.6W), +3.3V/5V combined 100W
- Connectors: 1x 12VHPWR, fully modular
- Efficiency: ~90% @20%, ~92% @50%, ~89% @100% load
- Certifications: 80+ Platinum, CE, CB, TUV, cTUVus, FCC, RoHS
| Wattage | 1000 W |
| Standard | Intel ATX 3.0 |
| Certification | 80 PLUS Platinum, CE, CB, TUV, cTUVus, FCC, RoHS |
| Input Voltage | 100–240 VAC |
| Input Frequency | 50–60 Hz |
| Input Current | up to 15 A |
| Active PFC | Yes |
| +3.3 V Rail Max Current | 20 A |
| +5 V Rail Max Current | 20 A |
| Combined +3.3 V & +5 V Output | 100 W |
| +12 V Rail Max Current | 80 A (999.6 W) |
| –12 V Rail | 0.4 A (4.8 W) |
| +5 VSB | 2.5 A (15 W) |
| PCIe 5.0 12VHPWR Connector | 1 × 600 W |
| Fan | 140 mm ECO Intelligent FDB fan, temperature-controlled |
| Efficiency | ~90% @20%, ~92% @50%, ~89% @100% load |
| Capacitors | 100% Japanese 105 °C capacitors |
| Protections | OVP, OCP, OPP, SCP, UVP, OTP, No-load, Surge & Inrush |
| Modular | Fully modular ribbon cables |
