Save 30.49 €
Ubiquiti UniFi Pro XG Switch - USW-PRO-XG-8-POE - 8x 10G RJ45 & 2x SFP+, PoE++ 155W, Managed L2/L3, Grey
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
Managed L2/L3 switch with 8x 10G RJ45 + 2x SFP+, 8-port PoE++ (4PPoE) with 155W budget, 200 Gbit/s switching capacity, 220W max power.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
Compact desktop/wall-mountable, professional-grade 8-port, Layer 3 Etherlighting™ PoE++ switch with (8) 10 GbE and (2) 10G SFP+ ports.
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| 10G Ethernet (copper) ports quantity | 8 |
| SFP+ module slots quantity | 2 |
| Power connector | DC-in jack |
| 10G support | Yes |
| Port mirroring | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| IPv4 routes | 12000 |
| VLAN support | Yes |
| Virtual LAN features | Interface-based VLAN, Voice VLAN |
| Number of VLANs | 1000 |
| Switching capacity | 200 Gbit/s |
| Throughput | 100 Gbit/s |
| Forwarding rate | 149 Mpps |
| MAC address table | 32000 entries |
| Static route | Yes |
| Jumbo frames support | Yes |
| Packet buffer memory | 2 MB |
| DHCP features | DHCP guarding, DHCP relay, DHCP server, DHCPv6 snooping |
| IGMP snooping | Yes |
| Loop protection | Yes |
| Multicast support | Yes |
| Rack mounting | No |
| Product colour | Grey |
| Housing material | SGCC |
| Reset button | Yes |
| LED indicators | System |
| Wall mountable | Yes |
| Power source | AC/DC |
| Power supply included | Yes |
| Power consumption (max) | 220 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE++ (4PPoE) |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 15.4 W |
| Total Power over Ethernet (PoE) budget | 155 W |
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Width | 210.4 mm |
| Depth | 173.8 mm |
| Height | 43.7 mm |
| Weight | 1.6 kg |
| Cables included | Power |
| Manual | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
