TP-Link Omada SG3210XHP-M2 - 8x 2.5G PoE+ & 2x 10G SFP+ L2+ Managed Rackmount Switch
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
L2+ managed 1U rackmount switch with 8× 2.5GBASE-T PoE+ ports and 2× 10G SFP+ uplinks. 16K MAC table and 80 Gbps switching capacity for SMB networks.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+. Switch type: Managed. Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500). Basic switching RJ-45 Ethernet ports quantity: 8. Console port: RJ-45/micro-USB. MAC address table: 16000 entries. Switching capacity: 80 Gbit/s. Networking standards: IEEE 802.1D. IEEE 802.1s. IEEE 802.1w. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting. Form factor: 1U
| Switch type | Managed |
| Switch layer | L2+ |
| Feature | Quick start guide |
| MIB support | RFC2925. RFC2618. RFC2620. RFC2021. RFC2819. RFC2674. RFC1493. RFC1643. RFC2233. RFC1213 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity | 8 |
| SFP+ module slots quantity | 2 |
| Console port | RJ-45/micro-USB |
| Power connector | AC-in jack |
| Networking standards | IEEE 802.1D. IEEE 802.1s. IEEE 802.1w |
| Ethernet LAN data rates | 100.1000.2500 Mbit/s |
| Virtual LAN features | MAC address-based VLAN. Port-based VLAN. Private VLAN. Protocol-based VLAN. Tagged VLAN. Voice VLAN |
| Number of VLANs | 4000 |
| Switching capacity | 80 Gbit/s |
| Forwarding rate | 59.52 Mpps |
| MAC address table | 16000 entries |
| Number of static routes | 48 |
| Number of IP interfaces | 16 |
| Jumbo frames | 9000 |
| Packet buffer memory | 12 MB |
| DHCP features | DHCP client. DHCP relay. DHCP server. DHCP snooping. DHCPv6 client. DHCPv6 snooping |
| Security algorithms | HTTPS. SSH. SSH-2. SSL/TLS |
| Authentication | MAC-based authentication. Port-based authentication |
| Authentication type | AAA. TACACS+ |
| Queue scheduling algorithms | SP. WRR+SP. Weighted Round Robin (WRR) |
| Management protocols | SNMPv1/v2c/v3. SNTP |
| Form factor | 1U |
| Product colour | Black |
| Number of fans | 2 fan(s) |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 285.9 W |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 240 W |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 975.54 BTU/h |
| Width | 440 mm |
| Depth | 180 mm |
| Height | 44 mm |
| Cables included | AC |
| Package type | Box |
| Certification | CE. FCC. RoHS |
