Seasonic FOCUS SGX-750 750W SFX PSU (ATX 2.4 Compatible) - 80 PLUS Gold, Fully-Modular, SSR-750SGX
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
Compact 750W SFX PSU (125×100×63.5mm) – 80 PLUS Gold certified, fully modular with SFX-to-ATX bracket. Hybrid fan control ensures quiet operation; 62A on +12V rail powers high-end SFF builds. 10-year warranty.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Seasonic FOCUS SGX-750 is a premium compact power supply designed for small form factor (SFF) systems. Measuring just 125 mm (L) x 100 mm (W) x 63.5 mm (H), this standard SFX unit fits perfectly in mini-ITX chassis while including an SFX-to-ATX adapter bracket for standard ATX cases, optimizing airflow space.
Certified 80 PLUS Gold with up to 92.5% efficiency at typical loads, it delivers 744W combined on the +12V rail (62A max). Fully modular cabling reduces clutter, and the hybrid S3FC fan control with a 92mm Hong Hua FDB fan stays silent below 30% load. Protection features include OPP, OVP, UVP, SCP, OCP, OTP. Backed by a 10-year warranty.
- 3x PCIe 6+2-pin (8/6-pin) GPU connectors for modern graphics cards
- 1x 4+4-pin EPS CPU connector
- 6x SATA, 3x Molex peripheral connectors
- 20+4-pin ATX motherboard connector
- Supports ATX 2.4 standard, full power up to 50°C
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Maximum input current (@110V) | 10 A |
| Maximum input current (@220V) | 5 A |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 744 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 62 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Motherboard power connector | 20+4 pin ATX |
| CPU power connector (4+4 pin) | 1x Yes |
| PCIe power connectors (6+2 pin) | 3x |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Power supply unit (PSU) form factor | SFX |
| Fan diameter | 9.2 cm |
| Number of fans | 1 fan(s) |
| Warranty | 10 years |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Cooling type | Hybrid fan control (S3FC) |
| Protection features | OPP, OVP, UVP, SCP, OCP, OTP |
| Width | 125 mm |
| Depth | 100 mm |
| Height | 63.5 mm |
| Operating temperature (T-T) | 0 - 50 °C |
