QNAP TS-664-8G NAS Server - 6-Bay, Intel Celeron N5095 2.0/2.9GHz, 8GB DDR4, 2x M.2, 2x2.5GbE, HDMI 2.1, Black/Bronze
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
6-bay QNAP TS-664-8G NAS with Intel Celeron N5095 (2.0–2.9GHz), 8GB DDR4 (expandable to 16GB), dual M.2, dual 2.5GbE, RAID support, hot-swap bays.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
QNAP TS-664. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: Intel® Celeron®. Processor model: N5095. Processor frequency: 2 GHz. Internal memory: 8 GB. Internal memory type: DDR4. Total installed storage capacity: 0 TB. Operating system installed: QNAP QTS
| Supported storage drive interfaces | M.2. Serial ATA III |
| Storage drive sizes supported | 2.5.3.5.M.2 |
| Number of M.2 (M & B) slots | 2 |
| Feature | Intel VT-x with Extended Page Tables (EPT) |
| RAID levels | 0. 1. 5. 6. 10. 50. JBOD |
| Supported file systems | FAT32. HFS+. NTFS. ext3. ext4 |
| Total installed storage capacity | 0 TB |
| Number of storage drives supported | 6 |
| Supported storage drive types | HDD & SSD |
| Processor manufacturer | Intel |
| Processor family | Intel® Celeron® |
| Processor model | N5095 |
| Processor frequency | 2 GHz |
| Processor boost frequency | 2.9 GHz |
| Processor cores | 4 |
| Processor threads | 4 |
| CPU configuration (max) | 1 |
| Number of processors supported | 1 |
| On-board graphics card model | Intel® UHD Graphics |
| Internal memory | 8 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 16 GB |
| Memory slots | 2 |
| Memory form factor | SO-DIMM |
| Flash memory | 4000 MB |
| Ethernet LAN data rates | 10.100.1000.2500 Mbit/s |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | Black. Bronze |
| Number of fans | 2 fan(s) |
| Fan diameter | 9 cm |
| LED indicators | HDD. LAN. Power. Status. USB |
| Cable lock slot type | Kensington |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup features | Cloud. iSCSI LUN |
| Management protocols | SNMP V2. V3 |
| Security algorithms | FIPS 140-2. HTTPS. SNMPv2. SNMPv3. SSH |
| Browser supported | Apple Safari. Google Chrome. Microsoft Edge. Mozilla Firefox |
| Operating system installed | QNAP QTS |
| Operating system version | 5.0.0 |
| Linux operating systems supported | Ubuntu 14.04 |
| Server operating systems supported | Windows Server 2008. Windows Server 2012 R2. Windows Server 2016. Windows Server 2019 |
| Other operating systems supported | Solaris 10 |
| Power supply location | External |
| Power supply unit (PSU) capacity | 120 W |
| Number of power supply units | 1 |
| Power consumption (typical) | 44.02 W |
| Power consumption (sleep) | 23.22 W |
| AC input voltage | 100 - 240 V |
| Fan voltage | 12 V |
| Width | 235 mm |
| Depth | 226 mm |
| Height | 168 mm |
| Weight | 2.9 kg |
| Package weight | 4.56 kg |
| Cables included | AC. LAN (RJ-45) |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
-
-
