CyberPower - OL3000ERTXL2U - 19' 2HE
CyberPower OL3000ERTXL2U online double-conversion UPS, 3 kVA/2700 W, 190-300 V input, 50/60 Hz output, 1335 J surge, 0 ms response, 9 outlets, 2U rack/tower, black metal enclosure.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
CyberPower OL3000ERTXL2U. UPS topology: Double-conversion (Online). Output power capacity: 3 kVA. Output power: 2700 W. AC outlet types: C13 coupler. C19 coupler. Power plug: C20 coupler. AC outlets quantity: 9 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA). Typical backup time at full load: 3 min. Typical backup time at half load: 11 min. Form factor: Rackmount/Tower. Product colour: Black. Housing material: Metal. Compliance certificates: BSMI. RCM. RoHS
| UPS topology | Double-conversion (Online) |
| Output power capacity | 3 kVA |
| Output power | 2700 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 190 V |
| Input operation voltage (max) | 300 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Maximum current | 15 A |
| Surge energy rating | 1335 J |
| Response time | 0 ms |
| Heat dissipation | 1139 BTU/h |
| Output power factor | 0.9 |
| Feature | Overload protection |
| Total Harmonic Distortion (THD) (linear load) | 3% |
| Total Harmonic Distortion (THD) (non-linear load) | 5% |
| Surge protection features | Fax. Modem. Network. Telephone |
| Power protection features | Overload. Short circuit |
| Audible alarm modes | Battery replacement |
| AC outlet types | C13 coupler. C19 coupler |
| Power plug | C20 coupler |
| AC outlets quantity | 9 AC outlet(s) |
| USB 2.0 ports quantity | 1 |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
| RS-232 ports | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Battery technology | Sealed Lead Acid (VRLA) |
| Typical backup time at full load | 3 min |
| Typical backup time at half load | 11 min |
| Battery recharge time | 5 h |
| Form factor | Rackmount/Tower |
| Housing material | Metal |
| Rack capacity | 2U |
| Cooling type | Active |
| Product colour | Black |
| Control type | Buttons |
| Display type | LCD + LED |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Compliance certificates | BSMI. RCM. RoHS |
| Cables included | Serial. USB cable |
| Width | 433 mm |
| Depth | 600 mm |
| Height | 88 mm |
| Weight | 32 kg |
| Bundled software | PowerPanel® Business Edition |
| Package width | 565 mm |
| Package depth | 880 mm |
| Package height | 240 mm |
| Package weight | 39.5 kg |
| Harmonized System (HS) code | 8504408590 |
| Warranty period | 3 year(s) |
| Country of origin | China |
| Battery type | RBP0076 |
| Compatible operating systems | Windows 7 / Vista / XP / 2000. Server 2008 / 2003. Linux |
