Cisco SMART - CBS220 - 24-PORT GE POE
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
Managed L2 Cisco CBS220 SMART switch with 24 PoE Gigabit ports and 4 SFP+ slots; rack-mountable.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
Cisco CBS220-24P-4X. Switch type: Managed. Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8192 entries. Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.3ab. IEEE 802.3ad. IEEE 802.3af. IEEE 802.3u. IEEE 802.3x. IEEE 802.3at. IEEE 802.3z….. Power over Ethernet (PoE). Rack mounting
| Switch type | Managed |
| Switch layer | L2 |
| Feature | Power over Ethernet (PoE) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
| Networking standards | IEEE 802.3ab. IEEE 802.3ad. IEEE 802.3af. IEEE 802.3u. IEEE 802.3x. IEEE 802.3at. IEEE 802.3z. IEEE 802.1D. IEEE 802.1w. IEEE 802.1x |
| Number of VLANs | 256 |
| Switching capacity | 128 Gbit/s |
| MAC address table | 8192 entries |
| Jumbo frames | 9216 |
| DHCP features | DHCP client |
| Access Control List (ACL) rules | 512 |
| IGMP entries | 256 |
| Security algorithms | SSL/TLS |
| Number of multicast groups filtered | 256 |
| Management protocols | SNMP |
| Product colour | White |
| Number of fans | 2 fan(s) |
| AC input frequency | 50 - 60 Hz |
| Power over Ethernet (PoE) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 195 W |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width | 440 mm |
| Depth | 257 mm |
| Height | 44 mm |
| Weight | 4.03 kg |
| Harmonized System (HS) code | 85176990 |
