Broadcom MegaRAID 9540-8i 12Gb/s PCIe 4.0 x8 RAID 0/1/10 8 Internal Ports
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
Broadcom MegaRAID 9540-8i RAID controller. PCIe 4.0 x8, 8 internal SAS/SATA 12Gb/s & NVMe ports. RAID 0,1,10,JBOD. SAS3808 ROC. Low profile MD2 form factor. MTBF 3M hours. Max 63 SAS/SATA +4 NVMe devices. Power 6W.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Broadcom MegaRAID 9540-8i is a high-performance Tri-Mode storage adapter designed for data centers, cloud, and HPC environments. It delivers 12Gb/s SAS/SATA and PCIe Gen4 NVMe connectivity via PCIe 4.0 x8 host interface, providing twice the bandwidth of previous generations with 75% more IOPS.
Featuring the SAS3808 RAID-on-Chip controller and 1x SFF-8654 (SlimSAS) connector for 8 internal ports, it supports up to 63 SAS/SATA drives and 4 NVMe devices. RAID levels include 0, 1, 10, JBOD with features like fast rebuild and hot spare support. Low profile MD2 form factor (155.7×68.9mm) fits most servers. Operating temp 0-55°C, MTBF over 3,000,000 hours, typical power 6W.
- ✅ PCIe 4.0 x8 host interface
- ✅ 8 internal ports: SAS 12Gb/s, SATA 6Gb/s, PCIe 4.0 NVMe
- ✅ RAID 0, 1, 10, JBOD
- ✅ Low profile card, no cache
- ✅ Broad OS support: Windows, Linux, VMware, FreeBSD
| Host Interface | PCIe 4.0 x8 |
| Internal Ports | 8 |
| Internal Connectivity | 1 x SFF-8654 (SlimSAS) |
| RAID Levels | 0, 1, 10, JBOD |
| Data Transfer Rate | 12 Gbit/s SAS / 6 Gbit/s SATA / PCIe 4.0 NVMe |
| Controller Chip | SAS3808 |
| Max SAS/SATA Devices | 63 |
| Max NVMe Devices | 4 |
| Form Factor | Low Profile MD2 (155.7 x 68.9 mm) |
| MTBF | 3000000 h |
| Operating Temperature | 0 - 55 °C |
| Power Consumption | 6 W |
| OS Support | Windows, VMware, RHEL, SUSE, Ubuntu, Citrix, CentOS, Debian, Oracle, Fedora, FreeBSD |
| MPN | 05-50134-03 |
| Features | S.M.A.R.T. support, Universal Backplane Management ready |
