ASRock E3C252D4U - micro-ATX LGA1200 Motherboard - Intel Xeon E-2300 support, DDR4 up to 32GB, ECC, AST2500 iGPU, Intel I210 LAN
ASRock E3C252D4U micro-ATX LGA1200 motherboard for Intel Xeon E-2300. 4x DDR4 DIMM (up to 32GB, ECC & non-ECC), PCIe Gen4 x16, M.2 SATA, Intel I210 Gigabit LAN, AST2500 (256MB).
For any questions about this item, availability, or delivery times, please contact us at 22 270068
Asrock E3C252D4U. Processor manufacturer: Intel. Processor socket: LGA 1200 (Socket H5). Compatible processor series: Intel® Xeon®. Supported memory types: DDR4-SDRAM. Maximum internal memory: 32 GB. Memory slots type: DIMM. Supported storage drive interfaces: M.2. SATA. RAID levels: 0. 1. 5. 10. Graphics card family: ASPEED. Graphics card: AST2500. On-board graphics card model: Aspeed AST2500. Ethernet interface type: Gigabit Ethernet. LAN controller: Intel I210
| Processor manufacturer | Intel |
| Processor socket | LGA 1200 (Socket H5) |
| Compatible processor series | Intel® Xeon® |
| Intel Xeon series | E-2300 |
| Supported memory types | DDR4-SDRAM |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Memory voltage | 1.2 V |
| ECC сompatibility | ECC & Non-ECC |
| Supported memory clock speed (max) | 2666 MHz |
| Maximum internal memory | 32 GB |
| Supported storage drive interfaces | M.2. SATA |
| Feature | Ethernet LAN |
| RAID levels | 0. 1. 5. 10 |
| Graphics card family | ASPEED |
| Graphics card | AST2500 |
| On-board graphics card model | Aspeed AST2500 |
| On-board graphics card memory | 256 MB |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Intel I210 |
| Motherboard chipset | Intel C252 |
| Component for | PC |
| Motherboard form factor | micro ATX |
| Motherboard chipset family | Intel |
| PCI Express x1 (Gen 3.x) slots | 1 |
| PCI Express x4 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| BIOS type | UEFI AMI |
| ACPI version | 6.2 |
| System Management BIOS (SMBIOS) version | 3.3 |
