Argus DIN rail power supply SDL24-60
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
The Argus power supply SDL24-60 from Inter-Tech is a cost-effective DIN rail power supply in a compact design with 24V= output voltage and 60 watt output power. The power supply is…
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Argus power supply SDL24-60 from Inter-Tech is a cost-effective DIN rail power supply in a compact design with 24V= output voltage and 60 watt output power. The power supply is intended exclusively for mounting on top-hat rails in distribution boxes inside buildings and converts a 230 V~ input voltage into a 24 V= output voltage. It is permanently connected to a 230 V AC voltage. In order to compensate for the resistance loss with different cable lengths and to obtain 24 V at the consumer, the output voltage can be readjusted on the potentiometer. An indicator light indicates the operation of the power supply.
| Typ | Power supply |
| Color | white |
| EAN | 4260455647960 |
| Manufacturer no. | 88882216 |
| Manufactured in | China |
| Suitable for | Mounting on top-hat rails in distribution boxes |
| Service | Potentiometer |
| Advertisement | Indicator light |
| Power supply - input voltage | 100 - 240 V |
| Suitable devices | UPS |
| power source | Power outlet |
| Security | Overload, over-voltage and short circuit protection |
| Feature | Start time 0.6s @ 115V 60Hz / 0.6s @230V 50Hz, rise time 80ms, support time 20ms / 80ms |
| More information | Switching current 40A @115V~ / 60A @230V~, current consumption 1.8A / 1A, standby consumption < 0.6W |
| Accessories - available | Instructions |
| Dimensions | Width: 40mm x Height: 92mm x Depth/Length: 100mm |
| Weight | 290 Gramm |
