Adastra RM240S v2 100V 4Z 240W FM/USB/BT 953.215UK
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
A rack-mountable 5-channel mixer amplifier, tailored to commercial sound installations, that can either be used as a 100V line amplifier or a standard low-impedance amp. Versatile input options include XLR (with switchable phantom power), mic/line jack, and RCA line. Features an inbuilt FM radio tuner, front-mounted SD and USB ports, and Bluetooth connectivity, all controlled via an integrated media player for hassle-free playback. A switchable ‘voiceover’ feature automatically lowers the background music volume when a signal is detected via mic input 1 and rear panel 24V contacts can mute all except mic input 1 when triggered.
- 2U 19" rack mountable (rack ears supplied)
- XLR input with switchable +20V phantom power – ideal for condenser microphones and paging microphones with chimes
- 2 x mic/line inputs, 2 x RCA line inputs, and 1 x RCA line output
- Switchable ‘voiceover’ feature
- Inbuilt media player with SD, USB and Bluetooth inputs and integrated FM radio tuner
- 100V line or 4-16 ohm speaker output
- 24V emergency mute contacts
- Option for mains or 24Vdc power
- Editable Bluetooth ID for unique pairing
- Power : output: 240Wrms
- Speaker : outputs: 4 x 100V zone / 8 Ohms / COM terminals
- Speaker switching: Zones 1, 2, 3, 4, All
- Mains power 110/240Vac, 50/60Hz (IEC)
- DC power 24Vdc (screw terminals)
- Inputs Mic XLR, 2 x mic/line jack, 2 x RCA line
- Input sensitivity : mic 1 (balanced) -53dBV
- Input impedance : mic 1 5k Ohms
- Input sensitivity : line (unbalanced) -15dBV (-18.5dBV line 5)
- Input impedance : inputs 2-5 1k Ohms
- Line output RCA
- Controls Mic1, mic/line2+3, line4+5, bass, treble, master volume
- Equalizer : bass 100Hz ±10dB
- Equalizer : treble 10kHz ±10dB
- Rear panel switches Phantom, Vox, Mic/Line (2 + 3)
- Phantom power +20V (mic 1 input)
- Audio source USB/SD player, FM tuner and Bluetooth receiver
- Emergency control 24V contacts – mute all except Mic.1 when triggered
- Bluetooth version 2.0
- THD <1.0
- Weight: 9.62kg
- Dimensions: 433 x 320 x 89mm
Specifications
| Amplifier Type | Mixer Amp |
|---|---|
| Power | 240W |
| Zones | 4 |
| Zone Control | On-Off |
| USB / FM / BT | Yes |
| Rack Mountable | Yes |
