QNAP TVS-h674T - i5-12400 32GB DDR4 NAS Tower - 6-Bay, Black, Intel i5 2.5–4.4GHz, 2x2.5GbE, 2x M.2
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
QNAP TVS-h674T 6-bay NAS tower with Intel Core i5-12400 (2.5–4.4GHz), 32GB DDR4, 2 M.2 slots, 2×2.5GbE, HDMI, USB-A + USB-C for SMB and prosumers.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
QNAP TVS-H674T-I5-32G. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: Intel® Core™ i5. Processor model: i5-12400. Processor frequency: 2.5 GHz. Internal memory: 32 GB. Internal memory type: DDR4. Installed storage drive type: HDD. Operating system installed: QNAP QTS
| Storage drive interface | Serial ATA III |
| Supported storage drive interfaces | M.2. Serial ATA II. Serial ATA III |
| Storage drive sizes supported | 2.5.3.5.M.2 |
| Number of M.2 (M & B) slots | 2 |
| Feature | USB copy function |
| RAID levels | 0. 1. 5. 6. 10. 50. JBOD |
| Supported file systems | FAT32. HFS+. NTFS. ZFS. exFAT. ext3. ext4 |
| Number of storage drives supported | 6 |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD & SSD |
| Processor manufacturer | Intel |
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor family | Intel® Core™ i5 |
| Processor model | i5-12400 |
| Processor frequency | 2.5 GHz |
| Processor boost frequency | 4.4 GHz |
| Processor cores | 6 |
| Processor threads | 12 |
| On-board graphics card model | Intel UHD Graphics 730 |
| Internal memory | 32 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 64 GB |
| Memory slots | 2 |
| Memory form factor | SO-DIMM |
| Flash memory | 5000 MB |
| Ethernet LAN data rates | 10.100.1000.2500 Mbit/s |
| Supported network protocols | IPv4. IPv6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4b |
| Ethernet LAN (RJ-45) ports | 2 |
| Concurrent connections | 3500 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | Black |
| Number of fans | 3 fan(s) |
| Fan diameter | 9 cm |
| Fan diameter 2 | 6 cm |
| LED indicators | HDD. LAN. M.2. Status. USB |
| Display type | LCD |
| Cable lock slot type | Kensington |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup features | Cloud. USB drive. iSCSI LUN |
| Management protocols | SNMP V2. V3 |
| Browser supported | Apple Safari. Google Chrome. Microsoft Edge. Mozilla Firefox |
| Share folder | Thick. Thin |
| Operating system installed | QNAP QTS |
| Operating system version | QTS 5.1.0 |
| Windows operating systems supported | Windows 10. Windows 11. Windows 7. Windows 8 |
| Linux operating systems supported | CentOS 7.0. SuSE Linux 12.0. SuSE Linux 12.3. SuSE Linux 15. Ubuntu 14.04 |
| Server operating systems supported | Windows Server 2008 R2. Windows Server 2012. Windows Server 2012 R2. Windows Server 2016. Windows Server 2019 |
| Other operating systems supported | IBM AIX 7.1. IBM AIX 7.2. Solaris 10 |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 350 W |
| Number of power supply units | 1 |
| Power consumption (typical) | 79.363 W |
| Power consumption (sleep) | 39.911 W |
| AC input voltage | 100 - 240 V |
| Width | 264.3 mm |
| Depth | 280.8 mm |
| Height | 188.2 mm |
| Weight | 6.36 kg |
| Package weight | 7.93 kg |
| Cables included | AC. LAN (RJ-45) |
| Power cables quantity | 1 |
| Number of screws | 56 |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
