Kingston ValueRAM KVR32S22S8/8 8GB DDR4 SO-DIMM 3200MHz CL22
B2B prices require verification
This is our wholesale store. Log in and verify your business account to see B2B prices, or go to the retail store to view consumer prices.
Kingston ValueRAM KVR32S22S8/8 8GB DDR4-3200 SO-DIMM laptop memory. CL22 1Rx8 non-ECC unbuffered module, 260-pin, 1.2V. JEDEC compliant for reliable notebook upgrades. RoHS, lifetime warranty.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
ValueRAM, Kingston’s industry standard memory, delivers award-winning performance and legendary Kingston reliability. The KVR32S22S8/8 is an 8GB DDR4-3200 CL22 1Rx8 SO-DIMM module designed specifically for laptops and compact systems. This unbuffered, non-ECC memory operates at 1.2V with JEDEC-standard timings of 22-22-22, ensuring broad compatibility and plug-and-play simplicity.
Featuring gold contact fingers, fly-by topology, and on-die VREFDQ calibration, it provides stable performance for multitasking, content creation, and everyday computing. Built with eight 1G x 8-bit FBGA components, this single-rank module meets RoHS and halogen-free standards. Kingston’s lifetime warranty guarantees peace of mind.
- 8GB capacity (1G x 64-bit)
- PC4-25600 (3200MT/s) speed
- 260-pin SO-DIMM form factor
- CL22 latency, 1.2V operation
- Non-ECC, unbuffered, single-rank
- Operating temp: 0-85°C
| Buffered memory type | Unregistered (unbuffered) |
| CAS latency | 22 |
| Internal memory | 8 GB |
| Memory layout (modules x size) | 1 x 8 GB |
| Internal memory type | DDR4 |
| Component for | Laptop |
| Memory form factor | 260-pin SO-DIMM |
| ECC | No |
| Memory voltage | 1.2 V |
| Row cycle time | 45.75 ns |
| Refresh row cycle time | 350 ns |
| Row active time | 32 ns |
| Country of origin | Taiwan |
| Lead plating | Gold |
| Operating temperature (T-T) | 0 - 85 °C |
| Storage temperature (T-T) | -55 - 100 °C |
| Compliance certificates | RoHS |
| Doesn't contain | Halogen |
| Width | 69.6 mm |
| Height | 30 mm |
| Harmonized System (HS) code | 84733020 |
| Rank | Single Rank (1Rx8) |
| Timing | 22-22-22 |
| SPD Speed | PC4-25600 (DDR4-3200) |
