DeepCool PL650D 650W white ATX 3.1 PSU, 80 PLUS Bronze certified. Features Active PFC, 12+4 pin PCIe for modern GPUs, 85%+ efficiency, Hydraulic Bearing 120mm fan. Non-modular, full protections, ideal for mid-range gaming PCs.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The DeepCool PL650D is a reliable 650W power supply unit in white finish, compliant with ATX 3.1 and EPS 12V standards. It delivers stable power with a single +12V rail at 648W, Active PFC, and full suite of protections including OPP, OVP, OCP, UVP, SCP, and OTP. Certified 80 PLUS Bronze with Cybenetics Silver efficiency (up to 89%), it’s perfect for mid-range gaming builds supporting modern GPUs via native 12+4 pin connector.
Non-modular design with flat black cables for easy installation: 20+4 pin ATX (560mm), 2x 4+4 pin EPS (735mm), 3x 6+2 pin PCIe (580mm), 1x 12+4 pin PCIe (590mm), 8x SATA, 2x Molex. Equipped with a quiet 120mm Hydraulic Bearing fan (HYB technology), operating 0-40°C. All cables are fixed for budget-friendly reliability.
- Key Connectors: 1x 20+4 ATX, 2x 4+4 EPS, 3x 6+2 PCIe, 1x 12+4 PCIe (ATX 3.1), 8x SATA, 2x Molex
- Efficiency: 80 PLUS Bronze / Cybenetics Silver
- Cooling: 120mm HYB fan, active cooling
- Protections: OPP/OVP/OCP/UVP/SCP/OTP/SIP
- Certifications: CE/FCC/RoHS/ErP
| Total power | 650 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 9 - 4.5 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 648 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 54 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Hold time | 16 ms |
| Efficiency | 85% |
| 80 PLUS certification | 80 PLUS Bronze |
| Cybenetics Efficiency | Silver (85-89%) |
| ATX version | 3.1 |
| PCI Express power connectors (6+2 pin) | 3 |
| PCI Express power connectors (16-pin) | 1 (12+4 pin) |
| EPS/ATX12V connectors (4+4 pin) | 2 |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Cabling type | Non-Modular |
| Bearing technology | HYB (Hydraulic) |
| Fan diameter | 12 cm |
| Product colour | White |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Operating temperature (T-T) | 0 - 40 °C |
