ASRock Phantom Gaming D OC Radeon RX 6500 XT 4GB GDDR6 2820 MHz
ASRock Phantom Gaming D OC Radeon RX 6500 XT with 4GB GDDR6, 2820 MHz boost clock, dual-fan cooling, PCIe 4.0 x16 interface. Supports HDMI 2.1, DP 1.4a up to 7680×4320. Requires 400W PSU and 1×8-pin. Ideal for 1080p gaming. Metal backplate included.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The ASRock Phantom Gaming D OC Radeon RX 6500 XT is a compact 4GB GDDR6 graphics card designed for budget 1080p gaming. Featuring AMD’s Navi 24 GPU with 1024 stream processors, it delivers a base clock of 2365 MHz and boosts up to 2820 MHz for smooth performance in modern titles at medium-high settings.
Equipped with a dual-fan open-air cooler and metal backplate, it maintains low temperatures efficiently while supporting up to two displays at 8K resolution via 1x HDMI 2.1 and 1x DisplayPort 1.4a. The 64-bit memory bus provides 144 GB/s bandwidth, though PCIe 4.0 x4 limitation may impact performance on older platforms. Requires a 400W PSU with 1x 8-pin connector.
- AMD Radeon RX 6500 XT GPU, 4GB GDDR6 at 18 Gbps
- Boost clock: 2820 MHz (Gaming: 2650 MHz)
- DirectX 12 Ultimate, OpenGL 4.6 support
- Dimensions: 240 x 129 x 42 mm, 459g card weight
- Active dual-fan cooling with metal backplate
| Graphics processor family | AMD |
| Graphics processor | Radeon RX 6500 XT |
| Processor frequency | 2365 MHz |
| Processor boost clock speed | 2820 MHz |
| Processor boost clock speed (Gaming mode) | 2650 MHz |
| Stream processors | 1024 |
| Maximum resolution | 7680 x 4320 pixels |
| Maximum displays per videocard | 2 |
| Discrete graphics card memory | 4 GB |
| Graphics card memory type | GDDR6 |
| Memory bus | 64 bit |
| Memory clock speed | 18000 MHz |
| Data transfer rate | 18 Gbit/s |
| Memory bandwidth (max) | 144 GB/s |
| Interface type | PCI Express 4.0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4a |
| DirectX version | 12 Ultimate |
| OpenGL version | 4.6 |
| Cooling type | Active |
| Number of fans | 2 fan(s) |
| Product colour | Black |
| Minimum system power supply | 400 W |
| Supplementary power connectors | 1x 8-pin |
| Weight | 459 g |
| Length | 240 mm |
| Depth | 42 mm |
| Height | 129 mm |
| Package type | Box |
| Harmonized System (HS) code | 84733020 |
| Backplate | Metal |
